Serrated design in the outside main groove assures high grip and braking force on lCE&SNow covered surfaces.
Deep and densely distributed grooves and steel sheet helps soften the tread and contributes to shortening braking distance on the ice-covered surface.
| SIZE | Load Index | Speed Rating | Standard Rim | Section Width (mm) | Overall Diameter (mm) | MAX LAOD SINGLE | MAX PRESSURE | TREAD DEPTH (MM) | ||
| KG | LBS | Kpa | PSI | |||||||
| 235/75R15 | 105 | T | 6 1/2J | 235 | 733 | 925 | 2039 | 300 | 44 | 9 |
| 215/65R16 | 98 | T | 6 1/2J | 221 | 686 | 750 | 1653 | 300 | 44 | 8.8 |
| 235/70R16 | 109XL | T | 7J | 240 | 736 | 1030 | 2271 | 340 | 50 | 9.1 |
| 265/70R16 | 112 | T | 8J | 272 | 778 | 1120 | 2469 | 300 | 44 | 9 |
| 215/60R17 | 96 | T | 6 1/2J | 221 | 690 | 710 | 1565 | 300 | 44 | 8.8 |
| 225/65R17 | 102 | T | 6 1/2J | 228 | 724 | 850 | 1874 | 300 | 44 | 8.8 |
| 245/65R17 | 107 | T | 7J | 248 | 750 | 975 | 2149 | 300 | 44 | 9 |
| 265/65R17 | 112 | T | 8J | 272 | 776 | 1120 | 2469 | 300 | 44 | 9 |
| 215/55R18 | 95 | T | 7J | 226 | 693 | 690 | 1521 | 300 | 44 | 9 |
| 225/60R18 | 100 | T | 6 1/2J | 228 | 727 | 800 | 1764 | 300 | 44 | 8.8 |
| 235/50R18 | 97 | T | 7 1/2J | 245 | 693 | 730 | 1609 | 300 | 44 | 9 |
| 235/55R18 | 100 | T | 7 1/2J | 245 | 715 | 800 | 1764 | 300 | 44 | 9 |
| 235/60R18 | 103 | T | 7J | 240 | 739 | 875 | 1929 | 300 | 44 | 8.8 |
| 235/50R19 | 99 | H | 7 1/2J | 245 | 719 | 775 | 1709 | 300 | 44 | 8.8 |
| 235/55R19 | 101 | T | 7 1/2J | 245 | 741 | 825 | 1819 | 300 | 44 | 9 |
| 245/55R19 | 103 | T | 7 1/2J | 253 | 753 | 875 | 1929 | 300 | 44 | 9 |
| 255/50R19 | 107XL | H | 8J | 265 | 739 | 975 | 2149 | 340 | 50 | 8.8 |
| 255/55R19 | 111XL | H | 8J | 265 | 763 | 1090 | 2403 | 340 | 50 | 8.8 |
| 275/40R20 | 106 | H | 9 1/2J | 278 | 728 | 950 | 2094 | 340 | 50 | 8.8 |
| 275/45R20 | 110 | H | 9J | 273 | 759 | 1060 | 2337 | 340 | 50 | 8.8 |
